FOUNDRY-MASTER Smart

High performance metals analysis on your desktop

Get a quote

The FOUNDRY-MASTER Smart is the ideal solution for the metal production and processing industry, providing cost-effective, reliable analysis. This new generation optical emission spectrometer offers high analytical performance at an extremely compact size.

This OES spark spectrometer offers very short start-up and measurement time, identification of duplex steels with nitrogen analysis and a unique spark stand, accessible from three sides.

Why choose the the FOUNDRY-MASTER Smart?

Compact size

The small foot-print of only 415 x 665 mm and weighing just 35 kg makes handling easy

Price-performance ratio

High analytical performance from powerful patented optics, including identification of Nitrogen in duplex steels

Further benefits

Very short start-up and measurement time, wide range of result forms and automatic storage

Tired of wasting your time searching for grades manually?

Our mobile spark OES analyzers come with the world’s largest metal database already installed. With more than 15 million records for over 350,000 materials from 74 countries, you’ll have easy access to the information you need with no time-consuming research in norms and grade catalogues.

FREE 60 day trial Download an update to your existing instrument

Technical specifications

Flat field Multi-CCD optics

Wavelength range: 175 - 420 nm

Computer system: External PC-Workstation with Microsoft® Windows® user interface

W / H / D: 415 x 280 x 665 mm
(W / H / D: 16.33” x 11.00” x 26.18”)

Weight: 35 kg (77 lbs)

Typical applications

Typical applications

Analytical mode / identification.

Majority of metals and their alloys.

Fe: alloys, cast iron alloys.

Al: alloys, cast alloys,…

Cu: bronze, brass, Cu-Ni,…

Ni: hasteloy ~inconel ~ monel,…

Ti: Ti pure, Ti.6-4 ~ Ti.8-Mn.

Mg-,Co-, Sn-, Zn alloys, solders and more…
